Valvetronic Eccentric Shaft Replacement Kit - BMW Up To 01/2011 / N55 / 135i / 335i & More

The N55 engine contains an eccentric shaft that controls the variable valve lift of the intake valves. This system is known as Valvetronic. This shaft may require replacement due to needle bearing failure or wearing at the worm drive for the actuator due to poor lubrication. This kit includes everything you need to professionally replace your eccentric shaft.



Kit Includes:


- (1) Valvetronic Eccentric Shaft (Genuine BMW)
- (6) Valvetronic Eccentric Shaft Needle Bearings (Genuine BMW)
- (1) Valvetronic Eccentric Shaft Oil Squirter (Genuine BMW)
- (1) Valvetronic Eccentric Shaft Actuator (Continental)
- (1) Valvetronic Actuator Seal (Elring)
- (6) Fuel Injector Seals (Genuine BMW)
- (1) Valve Cover Gasket (Victor Reinz)
- (6) Decoupling Element For Fuel Injector (Genuine BMW)
- (3) Screw Torx Drive M6X20 (Genuine BMW)
- (2) ASA Screw Thread-Forming M6X18 (Genuine BMW)
- (3) Spark Plug Recess Insert Gasket (Elring)



Part #'s


Valvetronic Eccentric Shaft

1-37-7-589-883 / 11 37 7 589 883 / 11377589883


Valvetronic Eccentric Shaft Needle Bearing

11-37-7-615-379 / 11 37 7 615 379 / 11377615379

11-37-7-500-978 / 11 37 7 500 978 / 11377500978

11-37-0-150-710 / 11 37 0 150 710 / 11370150710


Valvetronic Eccentric Shaft Oil Squirter

11-37-7-583-786 / 11 37 7 583 786 / 11377583786


Valvetronic Eccentric Shaft Actuator

11-37-7-603-979 / 11 37 7 603 979 / 11377603979

11-37-7-599-021 / 11 37 7 599 021 / 11377599021


Valvetronic Actuator Seal

11-37-7-502-022 / 11 37 7 502 022 / 11377502022


Fuel Injector Seal

13-53-7-591-006 / 13 53 7 591 006 / 13537591006

91-81-1-092-800 / 91 81 1 092 800 / 91811092800


Valve Cover Gasket

11-12-7-587-804 / 11 12 7 587 804 / 11127587804


Decoupling Element For Fuel Injector

13-53-7-577-649 / 13 53 7 577 649 / 13537577649


Screw Torx Drive (M6X20)

07-12-9-904-366 / 07 12 9 904 366 / 07129904366


ASA Screw Thread-Forming (M6X18)

11-36-7-609-963 / 11 36 7 609 963 / 11367609963


Spark Plug Recess Insert Gasket

11-12-7-573-439 / 11 12 7 573 439 / 11127573439
