FD5630-905S
Boostline Ford Focus RS Connecting Rod, 5.63 in. Length, 23 mm Pin, 49.99 mm Journal, 3/8 in. ARP 2000 Bolts, 4340 Steel, Patented Three-Pocket Design, Set of 1.
BoostLine connecting rods are designed from the ground up for high-power forced induction and nitrous applications. A patented, 3-pocket design, forged from premium 4340 steel, maximizes strength while minimizing rotating weight. This revolutionary design dramatically improves the rod’s big-end stability under tensile loads and provides a 60% improvement in bending strength and 20% stress reduction in tension compared to H-beam designs. All of these benefits make BoostLine rods ideal for high-cylinder pressure engine combinations.
- Purpose-Built For Boost High Boost and Ford Focus RS Applications
- Forged From Ultra-Strong 4340 Steel
- Patented Three-Pocket Design
- Capable of 1000 HP
- 3/8 x 1.600 in. ARP 2000 Fasteners
- High Quality APMCO Bronze Pin Bushing
- 26 Point Detailed CMM Inspection Report Included
| Rod Type |
I-Beam |
|---|---|
| Material |
Forged 4340 Steel |
| Center To Center Length |
5.630 IN |
| Pin End Bore |
23.00 MM |
| Journal Size |
49.99 MM |
| Main Bearing Bore Diameter |
53.000 MM |
| Big End Width |
25.65 MM |
| Pin End Width |
21.95 MM |
| Bolt Diameter |
3/8 IN |
