836026-5005S
Horsepower: 250 - 360
Displacement: 1.8L - 3.0L
Features
- ORIGINAL GT SERIES AERODYNAMICS
- 47mm TURBOCHARGER COMPRESSOR OPTION
- INTERNALLY WASTEGATED TURBINE HOUSING
- SOLD AS A COMPLETE TURBO (INCLUDES TURBINE KIT & ACTUATOR)
- BALL BEARING CONFIGURATION WITH WATER COOLED CHRA
- V-BAND TURBINE HOUSING OPTIONS
- BOLT-ON UPGRADE FOR NISSAN RB26DETT
| GT2860R | Compressor | Turbine | |||||
|---|---|---|---|---|---|---|---|
| HP: 250-360 Disp: 1.8L-3.0L | Inducer | Exducer | A/R | Inducer | Exducer | Trim | A/R |
| Turbo PN: 836026-5005S | 47mm | 60mm | 0.60 | 54mm | 47mm | 76 | 0.64 |
| Turbine Kits: GT28 | PN | A/R | Inlet | Outlet | Wastegate | Divided | |
| Kits not directly interchangable. Modifications required to the exhaust system to fit. | 827690-0005 | 0.64 | T25 | 5-Bolt | Wastegated | N | |
| 827690-0004 | 0.86 | T25 | 5-Bolt | Wastegated | N | ||
| 827690-0001 | 0.57 | V-Band | V-Band | Free Float | N | ||
| 827690-0002 | 0.72 | V-Band | V-Band | Free Float | N | ||
Compressor Map & Exhaust Flow Chart
Compressor Map
Exhaust Flow Chart
About Garrett GT Series Turbochargers
Garrett GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.
