Ford Racing Tremec Transmission Kit Magnum XL

• Gear Ratios
• 1st gear = 2.97, 2nd gear = 2.10, 3rd gear = 1.46, 4th gear = 1.00, 5th gear = .80, 6th gear = .63

• Trans mount isolated shifter and shift ball
• 700 lb-ft torque capacity
• New extended length tail section designed to eliminate the semi-remote shifter
• SFI-approved steel bellhousing
• Reuses the OEM hydraulic clutch relase system.

• Includes swap-specific steel crossmember and OE-quality rubber transmission mount,


NOTES:

Users will need to convert to a 26-spline clutch disc and 1-piece 31 spline slip yoke style prop shaft (not included).

Magnum XL transmissions are designed to accept the factory hydraulic release bearing from a 2005-current Mustang GT.

GT500 bearings may also be used but will require a custom adaptor to maintain proper stack up (not included).

2005-2010 Mustang applications are a direct plug-and-play with regards to the speedometer.

2011-2014 models will require speedometer recalibration via ECU tuning or a separate plug-in signal converter from sine to hall-efffect signal, such as the Abbott Enterprises ERA or Dakota Digital SGI-1  (Not included)

2015-2019 model installation kits are not currently available.
