ICON 22-23 Toyota Tundra 6in Stage 1 Suspension System

K53271 Overview
The 4-link brackets, upper links, and lower links are sold separately, allowing the 4-link system to be customized for your specific Ford Super Duty year range.
Standard
+0.75" Lift over stock
Rate Option #1
Read more
Key Features
Optimized design to fit 37" tires with full articulation (larger tires may fit but fender trimming and modifications will be required)
Maintains factory track width
Front coilover spacer kit with heavy duty steel construction
Provides 6" front suspension lift with only 4" of crossmember drop
Single piece high-strength ductile iron steering knuckles with built-in 4" drop
Hight clearance front crossmembers and front skid plate, CNC Laser Cut and brake-formed from 1/4-inch steel plate
Included sway bar drop brackets reduce bind in OE sway bar links
Front and rear heavy-duty bump stop brackets
High angle outer tie-roads feature durable, metal on metal greaseable tie rod ends
2.0 Aluminum Series rear shocks to improve rear suspension performance
Rear coil spring spacer kit to provide lift while retaining factory rear coil springs
Improved rear sway bar links and mounts, and rear track bar bracket to reduce bind in the rear suspension
Warranty
Installation Guide
CA Residents: Prop 65 Warning
WARNING
This product contains chemicals known to the State of California to cause cancer, birth anomalies, or other reproductive harm.
Specifications
Brand ICON Vehicle Dynamics
UPC 840103425313
Proxy Number 53271
Shipping Width 24.00 in
Shipping Length 25.00 in
Shipping Depth 9.00 in
Shipping Weight 273.0000 LB
Technical Notes
OEM Wheels & Tires Fitment: No
Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.625” Backspace / 16mm Offset
Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
APPLICATION NOTE #85: Advertised lift height ranges are for a stock equipped vehicle. Increasing weight of vehicle due to accessories will alter lift range.
APPLICATION NOTE #142: Not compatible with vehicles equipped with Load-Leveling Rear Height Control Air Suspension.
APPLICATION NOTE #144: Not compatible with TRD Pro
APPLICATION NOTE #153: Not compatible with Adaptive Variable Suspension (AVS) equipped vehicles
APPLICATION NOTE #154: Not compatible with Tundra SR5 equipped with TRD Sport package
APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
TECH NOTE: Requires minimum of 20" diameter wheels
System Components
51010 (qty: 1) | 22-24 TUNDRA FRONT BOX KIT 1
51011 (qty: 1) | 22-24 TUNDRA FRONT BOX KIT 2
51012 (qty: 1) | 22-24 TUNDRA REAR BOX KIT
51014 (qty: 1) | 22-24 TUNDRA FRONT SKID PLATE
51015 (qty: 1) | 22-24 TUNDRA 6" COILOVER SPACER KIT
51016 (qty: 1) | 22-24 TUNDRA REAR COIL SPACER KIT
51017 (qty: 1) | 22-24 TUNDRA FRONT SKID PLATE
56517 (qty: 2) | 22-24 TUNDRA 3.5" REAR 2.0 VS IR
