KELFORD TOYOTA GR YARIS PERFORMANCE CAMS

KELFORD TOYOTA GR YARIS PERFORMANCE CAMS

$1,659.63 CAD

Kelford Cams SKU: KEL267-B

<p>Earn [points_amount] when you buy this item.</p>
Description Availability

267-B

Stage 2 G16E-GTS Engine Cams. Street aplication to suit GR Yaris / GR Corolla G16E-GTS engine with upgraded turbo 54-64mm, producing 500-700hp. Great with ethanol blend fuel, E85. Requires valve spring upgrade. Kelford Cams recommend KVS264 spring and retainer kit.

Camshaft Specifications

ENGINE MAKE:
ENGINE MODEL:
PART NUMBER:
Toyota
G16E-GTS
267-B
VALVE CLEARANCE:
INTAKE:
Hydraulic
SET

EXHAUST:
Hydraulic
SET

AT THE:

AT THE:

CAM LIFT:
INTAKE:
6.63mm
EXHAUST:
6.63mm
ROCKER RATIO:
INTAKE:
1.735
EXHAUST:
1.735
NETT VALVE LIFT:
INTAKE:
11.50mm
EXHAUST:
11.50mm
ADVERTISED DURATION AT
0.10mm
INTAKE:
276°
EXHAUST:
286°
DURATION AT
1.00mm VALVE LIFT
INTAKE:
236°
EXHAUST:
246°
TIMING AT
1.00mm VALVE LIFT
IVO:

IVC:

EVO:

EVC:

SUGGESTED CENTRELINES:
INTAKE:
vari
EXHAUST:
vari
LIFT AT TDC

INTAKE:

EXHAUST:
