Ridetech 10-15 Chevy Camaro ShockWave System Rear TQ Series

11505411 Upgrade your 2010-2015 Camaro with TQ Series rear Shockwave air ride for track-ready handling and bolt-on installation. Rebound and dual compression adjustments provide precise tuning capability. Remote reservoirs provide consistent fluid temps in all environments, as well as easy access to compression tuning knobs. TQ “Track Quality” Series Shockwaves provide single rebound adjustment combined with dual-stage – high speed and low speed – compression adjustment. The high-speed adjustment feature allows tuning of instances that might induce a high-speed excursion of the piston rod. This includes rapid changes in suspension loading such as quick directional transitions in autocross competition. The high-speed adjustment also allows fine-tuning for impact harshness typically found during street driving such as potholes, speed bumps, and other road irregularities. Low-speed adjustment allows tuning of ride quality, as well as the general cornering characteristics of typical road course and winding road cornering use. TQ Series Shockwaves are the ultimate air suspension choice for autocross, track days, drag racing and ultra-high performance use.
With a large 1.834″ piston, heavy-duty 5/8″ shaft, and impact-forged bodies, TQ Series Shockwaves are built to perform and built to last. They’re backed by our exclusive 1,000,001 mile warranty. Ridetech develops our shock calibrations and spring rates through thousands of cross-country test miles, on our exclusive test track and at competition events from coast to coast. We understand the suspension needs of your Camaro better than any other company. Includes rear triple adjustable TQ Series Shockwaves with remote reservoirs 30″ braided line, and custom brackets for bolt-on installation. For matching front TQ Series Shockwaves, click HERE.
11505411_new_bag_FOX.pdf
Triple Adjustable Rear ShockWave Instructions
Download File
19-shock-tuning-guide.pdf
Shock Tuning Guide
Download File
TQ_Intake_Sheet.pdf
TQ Intake Sheet
Download File
System For
Ridetech StrongArm Suspension, Stock Suspension
Suspension Location
Rear
Suspension Type
Air Suspension
Year
2010, 2011, 2012, 2013, 2014, 2015
Make
Chevrolet
Model
Camaro
