CSF 16-24 Chevy Camaro 3.6L OEM Plastic Radiator

CSF 16-24 Chevy Camaro 3.6L OEM Plastic Radiator

$209.99 CAD

CSF SKU: csf3904

Description Availability

3904

Bottom Hose Fitting (in): 1 5/16 Left (in)
Box Height (in): 5 11/16
Box Length (in): 29 11/16
Box Weight (lbs): 10
Box Width (in): 23 3/4
Core Length (in): 20 5/8 (in)
Core Material: Aluminum
Core Thickness (in): 1 1/4 (in)
Core Width (in): 19 (in)
Cross-flow/ Down-flow: Cross Flow
Hazardous Material: No
Inlet Length (in): 19 1/2
Inlet Width (in): 1 1/2
No. Of Rows: 1
Oil Cooler (in): 14 3/4 (High-efficiency Plate Type)
Outlet Length (in): 19 1/2
Outlet Width (in): 1 1/2
Radiator Cap Supplied: No
Tank Material: Plastic
Tech Note: O.E.M. style Plastic tank & Aluminum core with quick-connect oil cooler fittings. Upgraded Heavy Duty Core. 11% Thicker 30mm vs OEM 27mm
Top Hose Fitting (in): 1 5/16 Right (in)
Make Model Qualifiers Year
Cadillac ATS
  • Position: N/A
  • 2.0L L4 1998cc 122ci
  • Turbocharged
 2016-2019
Cadillac ATS
  • Position: N/A
  • 3.6L V6 222ci
 2016-2019
Cadillac CTS
  • Position: N/A
  • 3.6L V6 222ci
 2016-2019
Cadillac CTS
  • Position: N/A
  • 2.0L L4 1998cc 122ci
  • Turbocharged
 2016-2019
Cadillac CTS
  • Position: N/A
  • 3.6L V6 3564cc 217ci
 2016
Chevrolet Camaro
  • Position: N/A
  • 2.0L L4 1998cc 122ci
  • Turbocharged
 2016-2023
Chevrolet Camaro
  • Position: N/A
  • 3.6L V6 222ci
 2016-2024
Reference Number Reference Name
13589 DPI
84352728 OEM
84352738 OEM
GM3010586 Partslink
