CSF factories are ISO/TSO certified;CSF Radiators are designed and built to High Performance Standards & sold worldwide for over 50 years - over 30 Million Units Sold!;Our Radiators are carefully engineered & Wind Tunnel Tested in labratory for Cooling Performance Validation;We have over 10,000 different models of Radiators that we manufacture & supply for all the leading brands of vehicles on the road
- OEM specified Plastic Tank-Aluminum Core Construction
- Tanks are made from Virgin Grade Engineered plastic resins, which are "Glass Filled" for added Strength & Durability
- Gaskets are made from Special Grade "EPDM" rubber to withstand extreme temperatures of up to -120°F
- Tubes - Welded Type or Latest Generation "B-Tube" Design
- Fins (Heart of Radiator) - High Performance "Multi-Louvered Design" - OEM Spec
- 100% leak tested before leaving factory at 150% of operating pressure
- Industry Best Packaging - "10 Foot Drop Test" Standard
- Drop-in Fit
- High Performance Transmission Cooler with special Built-in Turburlator, when applicable
- All components are installed, torqued, & tested on Radiator during assembly
| Bottom Hose Fitting (in): |
1 1/2 Right (in) |
|
|
|
|
|
|
|
| Core Length (in): |
37 9/16 (in) |
|
|
|
| Core Thickness (in): |
1 1/4 (in) |
|
| Core Width (in): |
23 3/8 (in) |
|
| Cross-flow/ Down-flow: |
Cross Flow |
|
|
|
| Inlet Length (in): |
23 13/16 |
|
| Inlet Width (in): |
1 15/16 |
|
|
| Oil Cooler (in): |
11 1/2 Left & Right (high-efficiency Plate Type) |
|
| Outlet Length (in): |
23 13/16 |
|
| Outlet Width (in): |
2 7/16 |
|
| Radiator Cap Supplied: |
No |
|
|
|
| Tech Note: |
O.E.M. style Plastic tank & Aluminum core with quick-connect outlet pipe & quick-connect oil cooler fittings. |
|
| Top Hose Fitting (in): |
1 5/16 Left (in) |
|
| Make |
Model |
Qualifiers |
Year |
| Chevrolet |
Silverado 2500 HD |
- Position: N/A
- 6.6L V8 6571cc 401ci
- Naturally Aspirated
|
2020-2024 |
| Chevrolet |
Silverado 3500 HD |
- Position: N/A
- 6.6L V8 6571cc 401ci
- Naturally Aspirated
|
2020-2024 |
| GMC |
Sierra 2500 HD |
- Position: N/A
- 6.6L V8 6571cc 401ci
- Naturally Aspirated
|
2020-2024 |
| GMC |
Sierra 3500 HD |
- Position: N/A
- 6.6L V8 6571cc 401ci
- Naturally Aspirated
|
2020-2024 |
| Reference Number |
Reference Name |
| 13885 |
DPI |
| 84565799 |
OEM |
| 84889155 |
OEM |
| GM3010625 |
Partslink |
