Ohlins 18-25 Harley Softail Slim, Street Bob, Low Rider, Dlx, Std STX Pro Shock 13.5in.

$1,899.22 CAD

Shipping calculated at checkout

Ohlins SKU: ohlHD 517

<p>Earn%20[points_amount]%20when%20completing%20this%20purchase.</p>

HD 517

Öhlins' STX46 American V-Twin shocks are made to improve the comfort and performance of your Harley-Davidson. Available in a variety of configurations, these shocks are specifically designed and tested to suit your bike model.



The newest addition to the STX46 Softail family is the fully adjustable STX46 American V-Twin rear shock, designed for Harley-Davidson Softail models (2018-). It features a monotube, high gas-pressurized design, with the reservoir and preload adjuster side-mounted just below the rider's seat on the right side. A Harley-Davidson side cover (part no. 54000321) is required if one is not already installed, as it provides better clearance for the hoses. A black lid is included to cover the hole in this cover where the OE preload adjuster is located.



With fully adjustable damping, you can tailor the rebound and compression damping behavior of the shock to match your riding style. The side-mounted hydraulic preload adjuster allows for easy spring preload adjustments to compensate for changes in rider and cargo weight—no extra tools required.



Features

STX single-tube design
Monotube shock with side-mounted reservoir
High-pressure nitrogen gas-charged
46-mm piston diameter
Adjustable rebound and compression damping
Hydraulic preload adjuster with remote handle
Multiple spring rates available to accommodate a wide range of riders
Top-level comfort, rideability, and performance
Hard-anodized precision CNC-machined components
Low-friction shaft and sealhead design
Fully serviceable and repairable
